Specifications:
| CCD: |
1/3” Sony Super HAD CCD |
| Picture Element: PAL: |
500(H)*582(V) |
| Horizontal Resolution: |
420TV Lines |
| Minimum Illumination: |
0.8Lux/F1.2 |
| S/N Ratio: |
>48dB |
| AGC: |
High/Low |
| Auto White Balance: |
AUTO |
| Back Light Compensator: |
On/Off switchable |
| Video Output: |
1.0Vp-p, 75Ohm, BNC connector |
| Power source: |
DC12V |
| Power Consumption: |
120mA+/-50mA |
| Focal Length: |
8.0mm |
| Aperture: |
Auto Aperture F1.6 |
| Angle of View: |
42° |
| M.O.D.: |
0.1M |
Specifications of Lens:
DC Auto-iris Monofocal Lens
- Image format: 1/3 inch
- Mount: CS
- Focal length: 8mm
- Aperture (f) : F1.6
- Angle of view: 42°
- M.O.D: 0.1m
- Notice: DC Drive
Power adaptor (option):
- EU version (model name: DSA-12.4-EU): 12V/400mA
- UK version (model name: DSA-12.4-UK): 12V/400mA
|
